安装方式

Cable Gland :

PG7: ? CABLE 4-6mm PG9 : ? CABLE 6-8mm. PG11 : ? CABLE 6-10mm.

1/2" NPTF : ? CABLE 8-10mm. SK(G1) : ? CABLE 4-8.6mm. SK(M1-M2) : ? CABLE 4-8.6mm. SK(P1-P2) : ? CABLE 3.5-5.5mm.

Conductor cross section :

0.50(20AWG). 1.50mm2(16AWG).

Fixing system :

Central fixing screw.

Max. screw torque IEC60947-1

(Central fixing screw) :

G1-G4-M1-M2-P2 series: Max. 0.5 N*m. P1 series: Max. 0.4 N*m.

Type of terminations :

Screw(with protection plate).

Contact material and treatment :

Brass + Silver plated.

Max. contact screw torque IEC60947-1 : G1-G4-M1-M2 series: Max. 0.5 N * m. P1-P2 series: Max. 0.4 N * m.

Housing material :

PA66 UL94-V2 standard.

PA66 UL94 -V0 ATEX approved. PA66 UL94 -V0 UL approved.

Internal core material :

PA66 UL94-V2 standard.

PA66 UL94-V0 ATEX approved. PA66 UL94-V0 UL approved.

Flammability resistance :

UL94-V2 - Standard. UL94 V0 ATEX approved. UL94-V0 - UL approved.

Protection class :

IP 65 / 66 / 67 (assembled).

Operating temperature :

-40°C +90°C Standard (with NBR gasket).

-40°C +125°C Standard (Black with Silicone gasket).

-20°C +85°C Atex approved.

-40°C +65°C (Transparent or Black) ULapproved(-UL).

-40°C +90°C (Black) ULapproved (-UL1).

-40°C +120°C (Black) ULapproved (-UL4).

Nominal current :

G1-G4-M1-M2 series: 10A.

P1-P2 series: 6A.

Max contact current :

G1-G4-M1-M2 series: 16A

P1-P2 series: 10A.

G1-G4-M1-M2 ATEX series: 10A*

P1-P2 series: 6A*.
